BEVERLY HILLS (CBSLA)  A stretch of Sunset Boulevard was closed Monday after a pipe leak turned into a full-blown water main break over the weekend.The water line leak was first discovered

at Sunset Boulevard and Alpine Drive Friday night. The leak grew into a water main break Sunday night, prompting crews to shut down the intersection and most of Sunset to Rexford Drive.Water service

was not interrupted, but the city of Beverly Hills is asking residents, businesses and visitors to conserve water and not water their landscapes for the next seven days.“Outdoor irrigation, please eliminate

that, and also indoor as well. Limit shower time, laundry loads, that type of thing, because we’re going to be on the reservoir water for several days,” Beverly Hills spokesman Keith Sterling said.

The leak appears to be coming from a 32-inch cast iron pipe installed in the 1940s.

 Superior Leak Detection Pinpoint Leak For The City Of Beverly Hills Water Main Break December 17,2018CBS Los Angeles







Utility & Underground Services Location



Underground services surveys are an important aspect of any site construction work. Most underground services can be detected using electromagnetic detection equipment which can normally determine depth and measurements for cables, metal pipes and drainage runs. However some non-conductive services, for example, fibre optic cables and plastic pipes, require more specialist equipment such as GPR (Utility Locating. .The latest electromagnetic service or ground radar locators are used to determine the position of most underground cables and pipes. All routes are site marked with biologically degradable paint. Drains can be located using electronic sondes emitting a signal from the pipe, which is then located on the surface. All this information can then be surveyed to provide a comprehensive record of on site services and depths.Our surveyors are fully conversant with health and safety procedures regarding entry into confined spaces. These procedures will always be used when required.Surveys will be undertaken to TSA Utility Guidance Note Standards. o

  • Utility location
  • Utility depth
  • Size of any subsurface underground services
  • Type of utility
  • Condition of utility



Utility Locating  (GPR)

Utility Utility Locating  survey equipment, we are able to provide an accurate survey of underground features and utilities.  By sweeping the required area on a grid system, the surveyor is able to see images on a screen, which is a cross section through the ground.  The evidence of items such as disturbed soil, voids and foreign objects (i.e. pipes, tanks, foundations etc.) can then be interpreted and cross-reference to their relevant ground locations, either immediately on site (‘mark to ground’) and / or on CAD.

Items that are usually detectable;

  • Archaeological investigations
  • Buried human remains (i.e. graveyard sites)
  • Culverts
  • Duct and cable routes
  • Excavation Routes
  • Foundations
  • Large solid objects
  • Pipe Routes (metallic and non-metallic)
  • Storage Tanks
  • Underground utilities
  • Voids in the ground and cavities


Electromagnetic Detection

In general,  Leak & Utility Surveying Services undertake to survey only for declared services

(i.e., services that appear on statutory record drawings).  We will of course Pinpoint to locate

and track any services not featured on records. If required and where possible depth estimations will

 be supplied.

Services included in an Electromagnetic Survey;

  • Computer cables
  • Foul and storm drainage pipes above 100mm in size where pipes are accessible
  • Electric supply cables of 440v to 66kv AC, which are live
  • Electric cables to street lighting
  • Metallic water pipes of 38mm and above
  • Metallic gas pipes of 38mm and above
  • Metallic fuel mains
  • Metallic pumping mains
  • Telecom services in ducts
  • Underground heating pipes





                   The Underground Service Specialist





              Concrete Imaging (Including Rebar Mapping)



      Concrete Floor Slab Surveys



       GPS Utility Surveys



        GPS Mobile Leak Detection Surveys



         Electromagnetic Induction



          GPS Electro Magnetic Utility Locating



           GPS Underground X-Ray Mapping



            GPS Underground Utility Surveys



            Ground Penetrating Radar GPR



             GPS Septic Tanks Location



                   GPS Utility Locating



               GPS Tank Location



                Thermal Imaging Leak Surveys



                 GPS Building Investigation



                  Forensic Support



                   Golf Course Mapping



                    GPS Cemetery Mapping



                     GPR Military Support





Municipal Leak Specialist





· Water Distribution Leak Surveys

· Water Treatment Plant Surveys

· Municipal Water Loss Audits

· Private Water Systems Leak Surveys

· Sewer Leak Surveys  & Sewer Line Location

· Commercial Utility Location Surveys
· Fire Hydrant Testing Surveys

· Ground Penetrating Radar Service

· Commercial Water Leak Detection

· Military Leak Surveys
· Gas Leak Surveys

· Natural Gas Leak Surveys

· Video Camera Pipeline Inspection Surveys

· Combustible Gas Leak Surveys
· Compressed Air Leak Surveys
· Compressed Air Audits

· Plant Leak Survey









Municipal Leak Contractors For Water Company









Underground Utility Color Chart





RED

Electric power line cables or conduit and lighting cables.

YELLOW

Gas oil, steam, petroleum or other hazardous liquid or gaseous materials.

ORANGE

Communication cable TV, alarm or signal line cable or conduits.

BLUE

Water, irrigation, and slurry lines.

GREEN

Sewer storm sewer facility or other drain lines.

WHITE

Proposed excavation

PINK

Temporary survey markings.

PURPLE

Reclaimed water, irrigation and slurry lines.
